MA7200

MA7200
€ 9.900,00

Deze versteker kan ik een van mijn favorieten noemen. Het is een transitor echter met een vleug "Buizenklank".

Met Monogrammed Heatsinks™ wordt de MA7200 niet warm ondanks het feit deze versterker is uitgerust met 2 x 200 watt. Wat deze versterker verder uniek maakt is de high current output transistors die opwarmtijd enorm inkorten. Daarnaast bezit de MA7200 nog meer McIntosh technologieën zoals Autoformers™ Hierdoor kan 200 Watt geleverd worden aan elke speaker ongeacht hun impedantie, Ohja, ook nog Power Guard®, Sentry Monitor™, Home Theater PassThru, en net zoals de MA5300 High Drive hoofdtelefoonversterker met Headphone Crossfeed Director (HXD®). Das uiteraard heel erg mooi maar waar het om gaat is hoe deze kwaliteitsversterker klinkt. Kom luisteren en overtuig jezelf.

Specifications:

  • Vacuum Tube or Solid State: Solid State
  • Output Type: Autoformer™
  • Output Meters: Yes
  • Dual Layer Chassis: Yes
  • Chassis Finish: Black painted steel
  • McIntosh Monogrammed Heatsinks™: Yes
  • Standby Power Requirement: <0.25 Watts
  • Power Output per Channel: 200 Watts
  • Number of Channels: 2
  • Speaker Impedance: 2, 4, or 8 Ohms
  • Rated Power Band: 20Hz to 20kHz
  • Total Harmonic Distortion: 0.005%
  • Dynamic Headroom: 2dB
  • Frequency Response +0,-0.5dB: 20Hz to 20kHz
  • Frequency Response, +0, -3dB: 10Hz to 100kHz
  • Sensitivity Phono (Moving Coil): 0.25mV
  • Sensitivity Phono (Moving Magnet): 2.5mV
  • Sensitivity High Level (Balanced / Unbalanced): 0.5V/0.25V
  • Sensitivity (Power Amp input): 1.4V
  • Signal To Noise Ratio (Moving Coil): 80dB
  • Signal To Noise Ratio (Moving Magnet): 82dB
  • Signal To Noise Ratio (High Level): 95dB
  • Signal To Noise Ratio (Power Amp input): 113dB
  • Input Impedance (Balanced / Unbalanced): 20K/20K
  • Damping Factor: >40
  • Maximum Output (Balanced / Unbalanced): 8V Unbalanced

Connectivity:

  • Balanced Input: 1
  • Unbalanced Input: 5
  • Phono Input Moving Coil: 1 (adjustable loading)
  • Phono Input Moving Magnet: 1 (fixed loading)
  • Upgradeable Digital Audio Module: Yes: DA1
  • Digital Coaxial Input: 2
  • Digital Optical Input: 2
  • Digital MCT Input: 1
  • Digital USB Input: 1
  • HDMI (ARC) Input: 0
  • Balanced Variable Output: 0
  • Unbalanced Fixed Output: 0
  • Unbalanced Variable Output: 2
  • Headphone Output: 1/4″ High Drive with Headphone Crossfeed Director (HXD®)
  • Subwoofer Output: 0
  • AM/FM Tuner option: No
  • Home Theater PassThru: Yes
  • Unbalanced Analog Connector Type: Standard
  • Speaker Binding Post Type: Standard
  • Service Port: 1

Digital:

  • Digital-to-Analog Converter (DAC) Type
  • 8-channel, 32-bit/384kHz PCM/DSD, Quad Balanced
  • Digital Coaxial Input Sample Rate: 24-bit/44.1kHz to 192kHz
  • Digital Optical Input Sample Rate: 24-bit/44.1kHz to 192kHz
  • Digital MCT Input Sample Rate: 16-bit/44.1kHz (CD), DSD64 (SACD)
  • Digital USB Input Sample Rate: 32-bit/44.1kHz to 384kHz (PCM), DSD64, DSD128, DSD256, DXD352.8kHz, DXD384kHz

Tone controls:

  • Tone Controls: Bass and Treble
  • Tone Bypass and Input Assign: Yes
  • RS232 Control Input: Yes
  • Power Control Output: 1 Main, 2 Trigger
  • Rear Panel Data Port: 4
  • Rear Panel IR Sensor Input: Yes
  • Input Level Match: Yes

Weight:

  • Unit Dimensions (W x H x D): 44.5cm x 19.4cm x 47.6cm
  • Unit Weight: 34.1 kg
  • Shipping Weight: 42.3 kg
